High Intensity Type A Aviation Obstruction Light Supplier

-


Model:CM-18-A
Operating Voltage:AC90-260V
Power consumption:≤100W
Flashing frequency:40～60times/min
Light intensity:Background Luminance
Light Intensity:
     ≤50Lux                          2000cd（±25%）
     50～500Lux                   20000cd（±25%）
     ＞500Lux                        200000cd（±25%）
Life span:＞100,000 hours
Emitting color:White
Beam angle:90° horizontal,3-7° vertical beam spread
Method of synchronization:Same power supply voltage signal mode
Overall size(mm):470mm×204mm×134mm
Installation size(mm):445mm×70mm×4-M10
Ingress protection:IP65
Lightning protection level:10KA
Operating temperature:-40℃～55℃
Net weight:8KG
Wind load:80m/sec.

Welcome to contact with me.Thanks
